SILVERSTONE POWERSUPPLY 750W GOLD ET750

Silverstone 750W+80 Gold Semi-Modular ATX Power SupplySilverstone ET750 Series semi-modular power supplies are certified 80 PLUS Gold for efficient power delivery with great performance .High efficiency with 80 PLUS Gold certificationSemi-modular cables facilitate cable management24/7 continuous power output with 40°C operating temperatureClass-leading single +12V railSilent running 140mm fan with 18 dBAPCIe 8pin and PCIe 6pin connectors supportAll-black flat cables designDual EPS 8pin with multiple PCI-E 8 / 6pin connectors support (V1.2) Silverstone Power Supply ET750 SpecificationsProduct No.Silverstone ET750 : SST-ET750-HGColorBlack（Lead-Free Paint）Max. DC Output750WPower density363W per literLoad RangeOUTPUT+3.3V+5V+12V+5VSB-12VMAX.(AMPS)22A22A62A2.5A0.3APEAK (AMPS)///3.0A/MIN.(AMPS)0A0A0A0A0ARANGE (%)±5%±5%±5%±5%±10%LINE REG.(%)±1%±1%±1%±1%±1%RIPPLE(MVP-P)50mV50mV120mV50mV120mV Combined +3.3V & +5V120WCombined +12V744WInput Voltage90 ~ 264 VrmsInput Frequency Range47Hz ~ 63HzPFCActive PFC（PF>0.9 at full load）Efficiency87% ~ 90% at 20% ~ 100% loadingMTBF100,000 hoursOperating temperature0°C ~ 40°CProtectionOver current protectionOver power protectionOver voltage protectionShort circuit protectionConnectorsV1.11 x 24 / 20-Pin motherboard connector (500mm)1 x 8 / 4-Pin EPS / ATX 12V connector (750mm)4 x 8 / 6-Pin PCIe connector (“500mm / 150mm†x 2)9 x SATA connector (“500mm / 150mm / 150mm†x 3)3 x 4-Pin Peripheral connector (500mm / 150mm / 150mm)1 x 4-Pin Floppy connector (500mm / 150mm / 150mm / 150mm)V1.21 x 24 / 20-Pin motherboard connector (500mm)*1 x 8-Pin EPS and 1 x 4-Pin + 4-Pin ATX 12V connector (750mm / 150mm)4 x 8 / 6-Pin PCIe connector (“500mm / 150mm†x 2)9 x SATA connector (“500mm / 150mm / 150mm†x 3)3 x 4-Pin Peripheral connector (500mm / 150mm / 150mm)1 x 4-Pin Floppy connector (500mm / 150mm / 150mm / 150mm)Cooling SystemSingle 140mm silent fanNoise Level18dBA minimumCertification80 PLUS GoldForm factorATXDimension150 mm (W) x 86 mm (H) x 160 mm (D)Weight2 Kg*Dual (CPU) EPS connectors is used in production batch with serial numbers starting 2029 or after.◠Specifications for Silverstone ET750 presented on this page contains most recent revisions and may differ from those printed on retail boxes or manuals. Check out Datcart Gaming PC in UAE Section includes high quality Power Supplies
