SILVERSTONE POWERSUPPLY 5.0 1200W PLATINUM

Product No.SST-HA1200R-PMModel (safety certification)SST-AX1200MCPT-AColorBlack (lead-free paint)Max. DC Output1200WPower density620W per literLoad RangeOutput+3.3V+5V+12V+5VSB-12VMax.(Amps)22A22A100A2.5A0.3AMin.(Amps)0A0A0A0A0ARange (%)±3%±3%+5/-7%±5%±5%Line Reg.(%)±1%±1%±1%±1%±1%Ripple(mVp-p)30mV30mV70mV40mV40mVCombined +3.3V & +5V120WCombined +12V1200WInput Voltage90 ~ 264 VrmsInput Frequency Range47Hz ~ 63HzPFCActive PFC (PF>0.9 at full load)Efficiency≥87% & <89% overall efficiencyMTBF100,000 hoursOperating temperature0°C ~ 50°CProtectionOver Current ProtectionOver Power ProtectionOver Voltage ProtectionShort Circuit ProtectionUnder Voltage ProtectionOver Temperature ProtectionNo load operationConnectors1 x 24 / 20-Pin motherboard connector2 x 8 / 4-Pin EPS / ATX 12V connector6 x 8 / 6-Pin PCIe connectors1 x 12+4-Pin 12VHPWR connector12 x SATA connectors3 x 4-Pin Peripheral connector1 x 4-Pin Floppy connectorCooling SystemSilent 135mm FDB fanNoise Level0 dBA minimumCertificationCybenetics PlatinumForm factorATX (PS2)Dimension150mm (W) × 86mm (H) × 150mm (D)5.91" (W) x 3.39" (H) x 5.91" (D)Weight2.9 kgOtherGPU Support list
